1. Welding displacement machinery and welding machine displacement machinery should have a wide speed range, welding operation speed, and good structural stiffness.

2、對尺寸和形狀各異的焊件，要有一定的適用性。

2. It is necessary to have certain applicability for welding components with different sizes and shapes.

3、在傳動鏈中，焊接變位機應具有反行程自鎖傳動，以免動力源突然切斷時，焊件因重力作用而發生事故。

3. In the transmission chain, the welding positioner should have a reverse stroke self-locking transmission to avoid accidents caused by gravity when the power source is suddenly cut off.

4、與焊接機器人和焊接作業配合使用的焊件變位機械，視焊件大小和工藝方法的不同，其到位精度(點位控制)和運行軌跡精度(輪廓控制)應控制在0.1-2毫米之間，精度應可達0.01毫米。

4. The positioning accuracy (point control) and running trajectory accuracy (contour control) of welding robots and welding operations used in conjunction with welding robots and welding operations should be controlled between 0.1 and 2 millimeters, with an accuracy of up to 0.01 millimeters, depending on the size and process method of the welding parts.

5、焊接變位機回程速度要快，但應避免產生沖擊和振動。

5. The return speed of the welding positioner should be fast, but impact and vibration should be avoided.

6、有良好的接電、接水、接氣設施，以及導熱和通風性能。

6. Having good electrical, water, and air connection facilities, as well as thermal and ventilation performance.

7、焊接變位機整個結構要有良好的密閉性，以免焊接飛濺物的損傷，對散落在其上的焊渣、藥皮等物應易被清理。

7. The entire structure of the welding positioner should have good airtightness to avoid damage from welding splashes. Welding slag, coating, and other objects scattered on it should be easily cleaned.

8、焊接變位機械要有聯動控制接口和相應的自保護功能集中控制和相互協調動作。

8. Welding displacement machinery should have linkage control interfaces and corresponding self-protection functions for centralized control and coordinated action.

9、工作臺面上應刻有安裝基線，裝各種定位工件和夾緊機構。

9. The workbench should be engraved with installation baselines, equipped with various positioning workpieces and clamping mechanisms.

10、兼作裝配用的焊件變位機械抗沖擊性能。并設有安裝槽孔，能方便地按其工作臺面要有較高的強度和抗沖擊性能。

10. Mechanical impact resistance of weldment displacement used for assembly purposes. And it is equipped with installation slot holes, which can easily press the workbench to have high strength and impact resistance.

11、用于電子束焊、等離子弧焊、激光焊和釬焊的焊件變位機械，應滿足導電、隔磁、絕緣等方面的特殊要求。

11. Welding displacement machinery used for electron beam welding, plasma arc welding, laser welding, and brazing should meet special requirements in terms of conductivity, magnetic insulation, and insulation.
